Leviton® LP210-MB

20 Space Indoor Load Center with Main Circuit Breaker

  • MPN: LP210-MB

  • IESPN: 252007

  • UPC: 078477821817

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability
Leviton® LP210-MB

Indoor Load Center, NEMA 1 with Main Circuit Breaker, 100 Amp, 20 Spaces, 22 KA Interrupt Rating, Enclosure and Interior Only


Leviton Indoor Load Centers are easy to install and feature a white enclosure housing white circuit breakers for a modern, appealing unit. All hot and neutral wires terminate at custom lugs in the panel, not at the circuit breaker*, so the entire panel can be wired at rough-in without circuit breakers installed. Branch circuit breakers are easily plugged-on at final installation. An optional observation window in the cover allows at-a-glance operating status of all the circuit breakers.


*For applications up to 60A when using copper wire; or 50A when using aluminum wire

*Designed for Leviton Circuit Breakers

  • pdfLP210-MB BROCHURE CARD https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Leviton-Load-Center-Brochure.pdf
  • pdfLP210-MB CATALOG CARD https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Leviton-Load-Center-Line-Card.pdf
  • pdfLP210-MB INSTALLATION https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/LPxxx-Instruction-Sheet-English.pdf
  • pdfLP210-MB SELL SHEET https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Load-Center_Sell-Sheet.pdf
  • pdfLP210-MB SPEC https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Leviton Load Center Indoor Spec Sheet,0.pdf

Color: White
Warranty: 10-Year Limited

Ground Connection: 4 AWG - 2/0 AWG Cu/Al
Supply Connections: 3 AWG - 300 MCM Cu/Al
Weight: 26 lbs.

Amperage: 100 A
Short Circuit Current Rating: 22 KA
Spaces / Circuits: 20 / 20
Type of Load Center: Main Breaker
Voltage: 120/240 VAC

NEMA Enclosure Type: NEMA 1 Indoor
Operating Temperature: -40°C to 85°C

Busbar Material: Copper, Bright Tin-Plated
Dimensions: 30" H x 14.25" W x 4" D
Enclosure Material: Galvanized Steel, White Powder Coat

UL 50: Yes
UL 50E: Yes
UL 67: Yes
UL 869A: Yes
