Philips Luminaires 8201BK

Philips Luminaires Lightolier Lytespan® 8201BK Compact Sculptural Style Track Head, R20/R30/PAR16/PAR20/PAR30/PAR38/Incandescent Lamp, 120/277 VAC

  • MPN: 8201BK

  • IESPN: 55693

  • UPC: 784197820114

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability
Philips Luminaires 8201BK

Philips Luminaires Lightolier Lytespan® Track Head, Compact Sculptural Style, R20/R30/PAR16/PAR20/PAR30/PAR38/Incandescent Lamp, 120/277 VAC, 150 W Lamp, Medium Lamp Base, 1 Lamp, 4 in Width, 4.7 in Length, Track Mount, Aluminum Housing, Matte Black Housing

Type      Compact Sculptural Style
Lamp Type      R20/R30/PAR16/PAR20/PAR30/PAR38/Incandescent
Voltage Rating      120/277 VAC
Lamp Wattage      150 W
Lamp Base      Medium
Number of Lamps      1
Width      4 in
Length      4.7 in
Mounting Type      Track
Housing Material      Aluminum
Housing Finish      Matte Black
  • pdfBrochure https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Lightolier_8201WH_Brochure.pdf
  • pdfBrochure-2 https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Lightolier_8201WH_Specification_Sheet.pdf
  • pdfInstallation Instructions https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Lightolier_8201WH_Installation_Instructions.pdf
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1520542656494.pdf
  • Combination of compact halogen sources with versatile and apartable fixtures delivers high impact lighting
  • Designed specifically around Par16/20/30/38 lamps, their crisp light creates dramatic effects of low voltage lighting
  • Spot distribution
  • Lytespan® attachment fitting - molded polycarbonate, integral color, fitter twists into track and locks on
  • Movable brass contact extends for connection to 2nd circuit in Advent® Lytespan® track
  • Bayonet receptacle to receive optional shade attachment
  • Rear vents for heat removal
  • Pivot mounting permanently tensioned, 350 deg stop for horizontal adjustment
  • Die cast aluminum socket housing
  • Trunion mounting tensioned with internal spring washer, 90 deg stop for vertical adjustment
  • Push tab detaches unit
  • Molded Valox® integral color screw cover
  • Porcelain socket, nickel plated screw shell #18 braided SF-1 leads
