Leviton® 8300-HGY

Share Print

Leviton® 8300-HGY Heavy Duty Slim Body Straight Blade Duplex Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Gray

  • MPN: 8300-HGY

  • IESPN: 72247

  • UPC: 078477818923

  • Min Order Qty: 1

  • Quantity Interval: 1

  • Sold as: EACH

    • Availability: loading

    • Branch Availability
Leviton® 8300-HGY

Leviton® offers a large selection of 15 and 20 Amp devices including residential, commercial and industrial grade receptacles, plugs and connectors, snap-in devices, as well as flanged inlets and outlets.

Leviton®, 8300-HGY, Straight Blade Duplex Receptacle, Heavy Duty Slim Body, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Hospital Grade, NEMA WD-1/WD-6 Enclosure, -40 to 60 deg C, Back/Side Wire Terminal, Thermoplastic, Gray, 4.06 in H x 1.51 in W x 1.18 in D Dimensions

Type      Heavy Duty Slim Body
Voltage Rating      125 VAC
Amperage Rating      20 A
Horsepower      1 hp
Number of Poles      2
Number of Wires      3
NEMA Rating      NEMA 5-20R
Grade      Hospital
Enclosure      NEMA WD-1/WD-6
Temperature Rating      -40 to 60 deg C
Terminal Type      Back/Side Wire
Material      Thermoplastic
Color      Gray
Dimensions      4.06 in H x 1.51 in W x 1.18 in D
  • Impact-resistant thermoplastic nylon cover and body
  • Smooth face does not collect dirt
  • Four corner latches securely fasten face
  • Extra heavy duty triple-wipe, brass T contacts for superior contact and conductivity
  • High-performance brass no 10-32 terminal screws to reduce conductor oxidation
  • Back and side wire ground termination brass strap version
  • Back and side wiring options
  • Break-off tabs for easy two-circuit conversion
  • Apron barrier to prevent accidental contact between terminal screw heads and metal box
  • Exclusive V-shaped, serrated back wiring clamps for superior contact and conductivity
  • Power Indication™ provides permanent green dot lens with 100000 hr LED status indicator
  • Nickel plated brass clamp nuts/ground clips
  • 14 to 10 AWG wire terminal
  • Full rated current limiting
  • 2000 VAC minimum dielectric strength
  • Self-grounding
