Decora® T5225

Decora® T5225 Tamper Resistant Duplex Combination Switch/Receptacle, 15 A at 120/125 VAC, 1 Pole, 14 to 12 AWG Wire

  • MPN: T5225

  • IESPN: 110406

  • UPC: 078477378588

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability
Decora® T5225

Leviton's standard combination switch/receptacle is the perfect choice for any area in a home. Its simple, functional design provides the use of a switch and a tamper-resistant receptacle in a one-gang space. Its impact-resistant exterior ensures damage protection and a long service life. These devices come in a range of colors and are backed by a limited two-year warranty.

Decora® Combination Switch/Receptacle, Tamper Resistant Duplex, 15 A at 120/125 VAC, 1 Pole, 14 to 12 AWG Wire, Threaded, Grade: Commercial, Side Wire Terminal, Thermoplastic, Brown

Type      Tamper Resistant Duplex
Electrical Rating      15 A at 120/125 VAC
Number of Poles      1
Wire Size      14 to 12 AWG
Mounting      Threaded
Grade      Commercial
Terminal Type      Side Wire
Material      Thermoplastic
Color      Brown
Warranty      2 Years Limited
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Decora_T5225_Data_Sheet.pdf
  • 1/2 hp HP rating, 12 A maximum amperage
  • Withstands 1500 V for 1 minute dielectric voltage
  • 100 cycles of OL at 4.8 times rated current overload UL 20 test
  • Maximum 30 degs C temperature rise
  • Rated V-2 per UL94 flammability
  • Thermoplastic body and actuator, steel strap material
  • Brass-hot black-hot white-neutral green-ground terminal id
  • Stamped on strap product id
  • 12-14 in pounds torque range
  • -40 to 65 deg C operating temperature
  • 15 A at 120 VAC toggle switch, 15 A at 125 VAC tamper resistant receptacle
