Lutron® Maestro™ 0 to 10 V dimmer sensors are lighting controls with passive infrared sensors that automatically control the lights in an area. These sensors detect heat from occupants moving within an area to determine when the space is occupied. The Maestro™ 0-10 V dimmer sensor combines a Maestro™ 0 to 10 V dimmer with an occupancy orvacancy Sensor.

Maestro® Occupancy Vacancy Sensor, 3-Way, Series: MS-Z101, 120 to 277 VAC, 8 A, Passive Infrared Sensor, 900 sq-ft Coverage, 180 deg Viewing, 1 to 30 min Delay, 50/60 Hz Response, Wall/Box Mount, 32 to 104 deg F, Ivory, 4-11/16 in H x 2-15/16 in W x 1-7/16 in D

• Specification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Maestro_MS_Z101_GR_Data_Sheet.pdf
• Video Link https://www.youtube.com/watch?v=BUG4UOLSYCs

• 0 to 10 VAC dimmer and vacancy PIR sensor, single pole/multi-location, single pole/multi-location, 8 A capacity
• Combined benefits of 0 to 10 VAC dimming and PIR occupancy/vacancy sensing to provide optimized dimming performance
• Superior sensing with Lutron®'s XCT sensing technology
• No neutral required, comes in occupancy/vacancy mode or vacancy only
• Controls 0 to 10 VAC electronic fluorescent ballasts, 0 to 10 V electronic LED drivers loads
• 8 A(electronic fluorescent ballast/LED driver), 1/6 hp at 4.4 A(fan)
• 400 sq-ft minor motion coverage
• 1/5/15/30 min (Adjustable) time delay
