GE IEC Contactor, Full Voltage Non-Reversing, Series: C-2000, 110/120 VAC Coil, 34 A at 460 VAC Maximum Load Current, 3 hp Coil, 3 Pole, 50/60 Hz Frequency, 25 kW Wattage, Non-Reversing Contact, 3NO Contact Configuration, Clamp Connection, Clamp Terminal, Open Enclosure, 20000000 Cycles Operating Cycles, -25 to 55 deg C Operating, Surface Mounting, 3.86 in H x 3.43 in W x 2.17 in D Dimensions

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ec4fc389b42aa59af5f8983492fbadeabd69097f5f46a8c5af7d0bf0d2b841ed.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ec4fc389b42aa59af5f8983492fbadeabd69097f5f46a8c5af7d0bf0d2b841ed.pdf

• Terminal numbering in accordance with EN 50005 and EN 50012
• Fixing by clipping onto 35mm DIN rail EN 50022-35 or by screws
• Screws protected against accidental contact in accordance with VDE 0106 T.100, VBG4
• Mounting possibilities of front/side instantaneous auxiliary contact blocks, timed auxiliary contact blocks, mechanical latch, transient suppressor block and interface modules
• Three coil terminals
• 14-10 AWG wire size
• 1000 V insulation voltage
• 16 lb-in torque
• 85 - 110 PCT of coil voltage pick up
• 40 - 55 PCT of coil voltage drop out
• 8 - 20 MS ON switching delay
• 6 auxiliary contacts
