Factory-terminated devices and connectors mean that device installation is the same regardless of skill level of the installer. The UL listed connectors are keyed to ensure proper wiring installation into each extra heavy-duty receptacle. The connector simply snaps into the back of the device - no fussing with wires, stripping or tightening screws. PlugTail® devices are finger safe with no exposed terminals, so taping is not required. Now device installation is a snap.

Pass & Seymour® PlugTail® Straight Blade Receptacle, 3-Phase Duplex Extra Heavy Duty, 125 VAC, 20 A, 2 Pole, 3 Wires, NEMA 5-20R, Commercial/Hospital Grade, -40 to 60 deg C, Polycarbonate/Thermoplastic, Black, 4.4 in H x 1.9 in W x 1.3 in D

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT5362CDGN_Installation_Manual.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT5362CDGN_Installation_Manual.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT8300LA_User_Manual.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT8300LA_User_Manual.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT8300LA_Specification_Sheet.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Pass_Seymour_PT8300LA_Specification_Sheet.pdf
• VIDEO LINK https://www.youtube.com/watch?v=_SjD8max4i0

• 0.036 in thick, brass, triple-wipe power contacts for lasting retention
• Large brass contacts snugly terminate on device blade terminals
• Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections
• Crimped and welded contacts
• Auto-ground clip assures positive ground
• Temperature Rise, Maximum 30 deg C temperature rise at full-rated current after 50 cycles of overload at 150 Percent of rated current with direct current
• Operating Temperature, Maximum continuous +60 deg C, minimum -40 deg C without impact
• PlugTail Connector - 12 AWG, THHN, copper conductor, 6 in leads, stripped, solid or stranded, for use with PlugTail Receptacles only
