GE TMP3L6R

Share Print

GE Mod™ III TMP3L6R 4-Wire Modular Metering Main Lug Module, 120/208Y/240 VAC, 600 A, 3 Phase, Bottom/Top Feed, NEMA 3R Enclosure

  • MPN: TMP3L6R

  • IESPN: 53941

  • UPC: 783164194203

  • Min Order Qty: 1

  • Quantity Interval: 1

  • Sold as: EACH

    • Availability: loading

    • Branch Availability
GE TMP3L6R

GE Mod™ III Modular Metering Main Lug Module, 4-Wire, 120/208Y/240 VAC, 600 A, 3 ph, Bottom/Top Feed, NEMA 3R Enclosure, 250 to 500 kcmil Wire, 100 kA Short Circuit, Center/End Mounting, 48.7 in H x 13.5 in W x 7 in D Dimensions

Type      4-Wire
Voltage Rating      120/208Y/240 VAC
Amperage Rating      600 A
Phase      3
Feed Type      Bottom/Top
Enclosure Type      NEMA 3R
Wire Size      250 to 500 kcmil
Short Circuit Current Rating      100 kA
Mounting Type      Center/End
Dimensions      48.7 in H x 13.5 in W x 7 in D
  • 100 kA interrupt rating
