EATON GHB2030

Share Print

EATON GHB2030 Type GHB Molded Case Circuit Breaker, 480Y/277 VAC/125/250 VDC, 30 A, 65/14 kA, 2 Poles, Non-Interchangeable/Fixed Thermal Magnetic Trip

  • MPN: GHB2030

  • IESPN: 54785

  • UPC: 786679911211

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability
EATON GHB2030

EATON's Series C molded case circuit breakers are used in panelboard, switchboard, motor control center and busway applications for dependable branch circuit protection. They have proven user acceptance for over 20 years and meet or exceed North American standards. Available for systems up to 600 VAC or 250 VDC with current ratings up to 2500 A.

EATON Molded Case Circuit Breaker, Type GHB, Series: C Series, 480Y/277 VAC/125/250 VDC, 30 A, 50/60 Hz Frequency, 65/14 kA Interrupt, G Frame, Non-Interchangeable/Fixed Thermal Magnetic Trip, 2 Pole, 3 Phase, Line/Load Connection, 10 to 1/0 AWG Wire, NEMA 4 Enclosure, Bolt-On Mounting, 40 deg C, 3.7 in L x 2.9 in W x 6.1 in H Dimensions

Type      Type GHB
Series      C Series
Voltage Rating      480Y/277 VAC/125/250 VDC
Amperage Rating      30 A
Frequency Rating      50/60 Hz
Interrupt Rating      65/14 kA
Frame      G
Trip Type      Non-Interchangeable/Fixed Thermal Magnetic
Number of Poles      2
Phase      3
Connection Type      Line/Load
Wire Size      10 to 1/0 AWG
Enclosure Type      NEMA 4
Mounting Type      Bolt-On
Temperature Rating      40 deg C
Dimensions      3.7 in L x 2.9 in W x 6.1 in H
  • pdfBrochure https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1520581848947.pdf
  • pdfBrochure https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://www.ideadigitalcontent.com/files/10964/ID-BRO-v1-SA012004EN.pdf
  • pdfCatalog https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Eaton_GHB2015_Catalog.pdf
  • pdfInstallation Instructions https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1520568049628.pdf
  • pdfInstallation Instructions https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://www.ideadigitalcontent.com/files/10964/ID-INS-v1-8703c67.pdf
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Eaton_GHB2030_Data_Sheet.pdf
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1520548860039.pdf
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://www.ideadigitalcontent.com/files/10964/ID-SPE-v1-TD012032EN.pdf
  • videoTechnical Drawing https://www.iesbuy.com/IDW_DOCUMENT_1518622376443.zip
  • videoTechnical Drawing http://www.eaton.com/ecm/idcplg?IdcService=GET_FILE&allowInterrupt=1&RevisionSelectionMethod=LatestReleased&Rendition=Primary&dDocName=98126783
  • Patented contact design features high speed "blow-open" action, resulting in superior performance
  • Circuit breakers significantly outperform the calculations listed in The Institute of electrical and electronic engineers (IEEE) standard 1584-2002, guide for performing arc flash hazard calculations
  • Choose from a complete family of trip units including thermal magnetic, electronic and magnetic only switches
