Resilient molded nylon blocks resist breakage and occupy minimum space on busy control panels. They are automotive approved to take the abuse of misguided screwdrivers. Ratings by wire size translate into amperes per circuit, according to the temperature limit of wire insulation and the internal panel ambient temperature. Fully shielded construction protects all live parts. Nylon has excellent anti-tracking qualities, as well as toughness and impact resistance.

GE Terminal Block, 12-Point Modular Resilient, Series: CR151K Series, 300/600 VAC, 20/50 A, 22 to 12 AWG Wire, Box Terminal, 5 mm Spacing, DIN Rail Mount, Feed-Through, 30 to 80 deg C, 0.88 in H x 2.39 in W x 1.09 in D

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_CR151KX008_Catalog.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_CR151KX008_Catalog.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_183acff3620ae025fb059a2c5ef558c8475a9f9bcdb523e2091a57663bdedd37.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_183acff3620ae025fb059a2c5ef558c8475a9f9bcdb523e2091a57663bdedd37.pdf

• Five circuits per inch give total of 12 circuits in 2.4 in L terminal block, equal to European 5 mm spacing
• Larger screws can take torque of standard screwdriver
• Larger, easier to wire openings take (1) 12 AWG or (2) 14 AWG wires
• Unique staggered design helps keep loose strands from shorting adjacent poles
• 1-piece design no end barriers and clips needed
• Extra wide marking area for pressure sensitive tape permits printing or marking prior to assembly, sliding marker design permits easy access to all screws
• Universal mounting fits all standard GE rails and mini DIN rails
