GE Industrial Solution Lighting Contactor, Electrically Mechanically Held, Series: CR463L, 110/115/120 VAC Coil, 30 A Maximum Load Current, 12 Pole, 50/60 Hz, Auxiliary Contact, 12NO, 30 A Contact, Open

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_CR463LD0AJA_Specification_Sheet.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_CR463LD0AJA_Specification_Sheet.pdf

• Contact position indication when button protrudes, contact is closed
• Power poles are available as single or double-poles, creating 74 different circuit combinations
• Convenient side access field power wiring
• Contact configuration indicator
• Standard base for all pole configurations
• Robust pole terminals accept upto two 8 AWG wires
• Manual operator
• Fast, sure 3-point mounting, enclosed contacts resist contaminants for greater reliability
• Combination slotted/2-Phillips® screws
• Common, easily installed power poles change from NO to NC (or vice versa) simply by unlatching and rotating 180 deg
• Power poles rated for the range of tasks
• 15 A motor rated
• A600 pilot duty rated easy to read rating label
• Auxiliary contacts, rated A600, are suitable for use on low level circuits down to 12 VAC, 5 mA
• Plug-in auxiliary contacts are no when installed on the left side of the base, NC on the right
• Finger and back of hand safe power terminals
• Quick-view coil voltage
• Easy change coil
• Low magnetic noise results in quiet operation
