New joint guard protection system dynamically indicates proper joint tension through color for easy installation and maintenance. Lighter weight mean faster installation than with other busway and lower installed cost that cable and conduit. Field adjustable isolation joint allows for +/-1/2 in per joint providing flexibility on the job site. Plug assist allows for faster, easier installation of plugs which provide power to downstream devices. Exclusive bluecoat epoxy insulation provides the industry's longest insulation life of 50+ years. Earth bond integral housing ground provides a lower resistance ground path than internal ground bars. Aluminum housing with sandwich design GE was the first to break the weight barrier with an aluminum housing that is up to 50% lighter than other busway.

GE Spectra™ Busway Fusible Plug, Type QMR Sandwich Bus Switch Operated, 480/600 VAC, 100 A Trip, 4 Wires, 200 kA Short Circuit, 3 ph, Aluminum

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_ACSB1G_Catalog.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_ACSB1G_Catalog.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_293d025c32c657dae13deffed77bff9982157ec39d78f578a8ff63790db11102.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_293d025c32c657dae13deffed77bff9982157ec39d78f578a8ff63790db11102.pdf

• Ground contact before stab contact
• Interlock to insure that plug is off when engaging bus and when removing plug
• Door interlock plug must be OFF to open door
• Without fuse
