These rubber insulated, dual rated connectors are for use in networks up to 600V. Suitable in light fixture pole bases in commercial, industrial or residential markets. Distribution within strip malls, for use in any multitenant facility. No taping or heat shrink required.

BURNDY® UNITAP™ Connector, 3-Port Type BIBS, Aluminum/Copper/Stranded Conductor, 12 AWG to 350 kcmil Run/Main, 600 VAC, 450 in-lb Installation Torque, 1-1/8 in L Wire Strip, 194 deg F, Aluminum, Unplated/Clear, 3.82 in L x 46 in W x 2.46 in H

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_BIBS3502DB_Full_Engineering_Drawing.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_BIBS3502DB_Full_Engineering_Drawing.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_BIBS3503DB_User_Manual.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_BIBS3503DB_User_Manual.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_BIBS3503DB_Specification_Sheet.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/BURNDY_BIBS3503DB_Specification_Sheet.pdf

• Dual rated for aluminum or copper conductors
• Each unit individually marked for ease of identification
• Supplied with aluminum set-screws
• Supplied with oxide inhibitor pre-installed
• Submersible rated and suitable for Direct Burial
