Q-Line circuit breakers are 1 in W per pole, compact, thermal magnetic devices designed for residential and commercial applications. The QC breakers are lug-lug versions of the Q-Line and are available for 35 mm DIN rail mounting. All Q-Line circuit breakers feature quick make/quick break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. Q-Line breakers are available in 1, 2 and 3-pole versions and can be ordered with auxiliary contact and shunt trip accessories.

GE Molded Case Circuit Breaker, Type THHQC, Series: Q-Line, 120/240 VAC, 35 A, 50/60 Hz Frequency, 22 kA Interrupt, Thermal Magnetic Trip, 1 Pole, 1 ph, Pivot Handle Actuator, Line Lug Connection, 14 to 6 AWG, 12 to 2 AWG Wire, DIN Rail Mounting, 10 to 50 deg C, 3-9/32 in H x 1 in W x 2-3/8 in D Dimensions, Plastic

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_THHQC1130LL_Catalog.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_THHQC1130LL_Catalog.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_TEB111010_Technical_Bulletin.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_TEB111010_Technical_Bulletin.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_TEB111010_Warranty.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/GE_TEB111010_Warranty.pdf

• Copper stabs, tin plated for corrosion resistance, make the connection reliable and permanent
• Heat resistant thermoset cases and covers add stability and structural rigidity
• Trips are easy to spot because handles trip to the center position
• The dedicated calibration screw is cemented (not simply papered over) to prevent shifting, the result is stable calibration for optimum trip performance
