Power Sentry® batteries fit in the tightest of applications, including low profile lensed troffers, downlighting and industrial lighting fixtures. They also feature an innovative Quick-Disconnect wiring harness that makes field maintenance and upgrades quick and easy. Specification grade emergency ballast to operate one or two lamps (4 ft or shorter) or one 8 ft lamp. Factory or field installed inside or outside (field only) fluorescent fixture to operate lamp(s) at a reduced light output, providing optimum glare free illumination for a minimum of 90 min upon interruption of normal power.

Lithonia Lighting® Emergency Ballast, Battery Pack, Series: PS1400DW, Fluorescent Lamp, 3 W, 120/277 VAC, 0.27/0.25 A, 50/60 Hz, 1 Lamp, T12/T8 Lamp Base Type, 32 to 100 deg F, Fixture Mount, Steel, Black, 13-15/16 in L x 2-3/8 in W x 1-5/8 in H

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b197dd61564b751360f26d37dae7546eae8bf1748fb03553a274023bfd6baf32.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b197dd61564b751360f26d37dae7546eae8bf1748fb03553a274023bfd6baf32.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_5f935439b3a1f6dc831ed9a47306380a6e0c852b96bfb2d191e3263e149499bb.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_5f935439b3a1f6dc831ed9a47306380a6e0c852b96bfb2d191e3263e149499bb.pdf

• Automatic battery recharge after 90 min discharge
• Constant current series resistor type charger
• Sealed, maintenance free, high temperature range nickel cadmium battery ensures long life over wide temperature ranges
• For indoor environment
• Black, 20 ga steel, permanently sealed housing
• Housing provides extra room for wire routing in ballast channel
• Polarized quick-connect pilot light/test switch assembly simplifies installation
• Patent pending integrated test switch pilot light that requires only one-hole drilling
• Ensures long life over a wide range of temperature ranges
• External battery connectors allows emergency ballast to be disabled for maintenance and installation
• Pilot light and test switch provide visual and manual means of monitoring system operation
• Capacitive input circuit provides high efficiency and reliable operation
• High efficiency push-pull inverter is the most effective method of converting DC power to AC power
• It provides maximum light output, battery life and reliability
