3M™ 5411/5412 series molded rubber QS II splice kit is a 1 piece in-line splice designed to use on 15 kV jacketed concentric neutral (JCN) or concentric neutral (CN) cables. The cold shrink jacket has peroxide cured EPDM rubber construction to ensure moisture resistance and durability. 3M™ 5411/5412 series molded rubber QS II splice kit is suitable to use on cables that can withstand a maximum temperature of 90 deg C. It provides an electric connection of outer conducting jacket to a cable semi-conductive jacket. The kit meets the requirements of ieee 404 standards.

3M™, 5411A, Splice Kit, Molded Rubber, Series: QS-II 5411A, 15 kV, Concentric Neutral/Jacketed Concentric Neutral Cable, 0.6 in Diameter Cable, 1 AWG, 1/0 AWG, 2/0 AWG Conductor, 0.775 to 0.9 in OD Insulation, 9 in Splice Length, 1 Conductors, 194 deg F, EPDM Rubber, Black, 1.76 in Dia Dimensions

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_8268925cf0cf0fb45519c108a653a4d42e9467dc3e407ddfe0035a9cd7f32794.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_8268925cf0cf0fb45519c108a653a4d42e9467dc3e407ddfe0035a9cd7f32794.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b1257bfed7dcaf44b3c2440a1145d065f63d1353e471d8c9bb1d165ac4115f46.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b1257bfed7dcaf44b3c2440a1145d065f63d1353e471d8c9bb1d165ac4115f46.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_607b1ef2c72b0a9567e3dec0c3664934f6d0addb551b80eff850efc4817a0e98.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_607b1ef2c72b0a9567e3dec0c3664934f6d0addb551b80eff850efc4817a0e98.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_d7196458b2b99f54ba3b473a3ceecc0ff15420f16009bfe904f13b0595829fa1.PDF https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_d7196458b2b99f54ba3b473a3ceecc0ff15420f16009bfe904f13b0595829fa1.PDF

• One piece in-line splice to use on jacketed concentric neutral (JCN) or concentric neutral (CN) cables
• Provides an electrical connection for the outer conducting jacket to the cable semi-conductive jacket
• Designed to use on cables that can withstand a maximum temperature of 194 deg f
• The cold shrink jacket is made of peroxide cured EPDM rubber which provides moisture resistance and durability
• Factory tested to offer reliability
• 900 psi tensile strength
• 570% elongation
• 1177 V/mil at 25 mil gap, 518 V/mil at 100 mil gap dielectric strength
• 1 AWG, 1/0 AWG, 2/0 AWG stranded and 1/0 AWG size solid conductors size
• 1/case
• 1 AWG, 1/0 AWG, 2/0 AWG stranded, 1/0 awg solid conductor size
