Leviton® H6A10-11R

Leviton® H6A10-11R Electro-Mechanical Dimmer, 120 VAC, 1 Poles, On/Off Operation, White

  • MPN: H6A10-11R

  • IESPN: 84716

  • UPC: 078477218327

  • Min Order Qty: 1

  • Quantity Interval: 1

  • Sold as: EACH
    • Availability: loading

    • Branch Availability
Leviton® H6A10-11R

Leviton® offers many products that will help lower electrical costs and add convenience to everyday living. By simply replacing standard switches with dimmers reduces energy consumption and extends bulb life. IllumaTech® Preset Dimmers and Fan Speed Controls feature a low profile fluid slide bar movement for fine adjustment of light levels or fan speeds that accompanied by an easy-to-use ON-OFF preset switch. The switch provides quick ON-OFF control without disturbing your favorite pre-selected settings. Most feature a built-in LED locator light, as well. Models are available for incandescent, magnetic or electronic low voltage, and Mark 10® Powerline dimming ballast fluorescent lighting, and quiet and standard fan speed control. All Preset models are designed for both single-pole (one-location) and 3-way (multi-location) applications.

Leviton® Dimmer, Electro-Mechanical, 120 VAC, 600 W Power, 60 Hz Frequency, 1 Pole, Magnetic Low Voltage Lamp, Operation Mode: On/Off, Pre-Set Slide Control, Wall Mounting, 0 to 55 deg C, White, 4.13 in H x 1.73 in W x 1.53 in D Dimensions

Type      Electro-Mechanical
Voltage Rating      120 VAC
Power Rating      600 W
Frequency Rating      60 Hz
Number of Poles      1
Lamp Type      Magnetic Low Voltage
Operation Mode      On/Off
Control      Pre-Set Slide
Mounting Type      Wall
Temperature Rating      0 to 55 deg C
Color      White
Dimensions      4.13 in H x 1.73 in W x 1.53 in D
  • All SureSlide® devices have a permanently mounted smooth action integrated linear slide control for easy, precise operation
  • SureSlide® Slide Dimmers and Fan Speed Controls offer full range slide control, pre-set versions feature a separate On-Off Preset switch that does not disturb the selected brightness or fan speed settings
  • SureSlide® dimmers and fan speed controls feature Elegant Decora® styling that coordinates perfectly with Leviton® extensive line of Decora® wiring devices
  • SureSlide® lighting controls are available in single-pole, 3-way and illuminated versions
  • SureSlide® features models specifically designed for Advance Mark XTM and Philips® EcotronTM fluorescent dimming ballasts and the Philips® dimmable Earthlight
  • Built-in radio/TV interference filter
  • Preset versions provide a low end trim adjustment feature allows precise adjustment of lamp brightness or fan speed at low end setting
  • SureSlide® quiet fan speed controls have special circuitry to reduce fan motor noise at low speeds
  • Radio/TV Filter protection
  • 20 to 90% relative humidity non-condensing, flammability (rated V-2 per ul94) environmental conditions
