GE TJD422400WL

Share Print

GE TJD422400WL Type TJD Molded Case Circuit Breaker With Lugs, 240 VAC/250 VDC, 400 A, 10 to 22 kA, 2 Poles, Long Time/Instantaneous Trip

  • MPN: TJD422400WL

  • IESPN: 4091

  • UPC: 783164049213

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability
GE TJD422400WL

GE Molded Case Circuit Breaker, Type TJD, 240 VAC/250 VDC, 400 A, 10 to 22 kA Interrupt, Q Series Frame, Long Time/Instantaneous Trip, 2 Poles, 1-Phase, Cable In/Cable Out (Lug-Lug), 10-1/8 in H x 8-1/4 in W x 3-13/16 in D

Type      Type TJD
Voltage Rating      240 VAC/250 VDC
Amperage Rating      400 A
Interrupt Rating      10 to 22 kA
Frame      Q Series
Trip Type      Long Time/Instantaneous
Number of Poles      2
Phase      1-Phase
Connection Type      Cable In/Cable Out (Lug-Lug)
Dimensions      10-1/8 in H x 8-1/4 in W x 3-13/16 in D
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1520586127657.pdf
  • Non-interchangeable trip
  • Standard continuous current rated
  • For reverse feed
  • The TJD line of devices include thermal magnetic molded case circuit breakers and molded case switches
  • The devices are complete with Cu/Al line and load lugs
