GE THQB2120GF

GE THQB2120GF Q-Line® Type THQB Ground Fault Circuit Breaker, 120/240 VAC, 20 A, 10 kA, 2 Poles, Non-Interchangeable/Fixed Thermal Magnetic/LIG Trip

  • MPN: THQB2120GF

  • IESPN: 8515

  • UPC: 783164400021

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability
GE THQB2120GF

Q-Line® circuit-breakers are 1 in wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QB breakers are bolt-on versions of the Q-Line® used for bolting to the bus connections of load centers and lighting panels. All Q-Line® circuit-breakers feature quick-make / quick-break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. Q-Line® breakers are available in 1, 2 and 3-pole versions, can be ordered with auxiliary contact and shunt trip accessories and can be ordered for use in HID applications.

GE Ground Fault Circuit Breaker, Type THQB, Series: Q-Line®, 120/240 VAC, 20 A, 10 kA Interrupt, Non-Interchangeable/Fixed Thermal Magnetic/LIG Trip, 2 Poles, 1-Phase, 14 to 8/12 to 8 AWG Wire, Bolt-On Mount, 3-9/32 in H x 2 in W x 2-3/8 in D

Type      Type THQB
Series      Q-Line®
Voltage Rating      120/240 VAC
Amperage Rating      20 A
Interrupt Rating      10 kA
Trip Type      Non-Interchangeable/Fixed Thermal Magnetic/LIG
Number of Poles      2
Phase      1-Phase
Wire Size      14 to 8/12 to 8 AWG
Mounting Type      Bolt-On
Dimensions      3-9/32 in H x 2 in W x 2-3/8 in D
  • pdfCatalog https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/GE_TJK436F000_Catalog.pdf
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/GE_THQB2120GF_Datasheet.pdf
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1518583893350.pdf
  • pdfSpecification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://www.ideadigitalcontent.com/files/NEURSPE/20153.pdf
  • Suitable for reverse feed
  • Standard continuous current rated
  • Fixed long time
  • Ground fault circuit interrupter (5 mA)
  • HACR special markings
  • Fixed instantaneous trip function
  • Copper/aluminum wire
