These unique, adaptable, field-programmable sensors utilize exclusive SmartSense technology—featuring an embedded microprocessor—to perform special sensing functions at extended ranges. These capabilities include programmable attributes, such as sensing range, output types, contact types, response time and noise immunity. No other sensor on the market offers such extensive programmability.

EATON Proximity Sensor, Straight Standard Range Shielded, Series: iProx, Inductive Sensing Method, 4 mm Sensing Distance, End Sensing Position, <1 % Accuracy, NPN/PNP Output, NC Contact Configuration, 6 to 48 VDC, 300 mA, 3-Wire 4-Pin M12 Pigtail Connection, 12 mm Dia Size, NEMA 4/4X/6/6P/12/13/IP67/IP69K Enclosure, -40 to 158 deg F, Flush Mounting, Polycarbonate/303 Stainless Steel

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/E59_M18A108C02_D2_User_Manual.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/E59_M18A108C02_D2_User_Manual.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_E59-M12A105D01-D2_Specification_Sheet.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_E59-M12A105D01-D2_Specification_Sheet.pdf
• VIDEO LINK https://www.youtube.com/watch?v=baa_aiJ4L7E

• Reliably detect metal targets at up to three times the range of conventional shielded or unshielded tubular inductive sensors
• Quality construction using a stainless steel barrel, 360 deg dual color LED indicator, Ryton® impact-resistant face cap and vibration-absorbing potting compound
• AUTO configure technology automatically detects a sinking (NPN) or sourcing (PNP) connection and switches the sensor accordingly, without any user intervention
• Exclusive SmartSense™ embedded microprocessor technology allows for customizable range, band sensing, nuisance metal rejection, timing delays and over/under speed detection
• Withstands high electrical noise (up to 20 V/m)
• Resistant to extreme temperatures (-40 deg F)
