Eaton’s Electronic Trip Units are designed to meet a broad range of monitoring and protection requirements. Curve shaping, zone selective interlocking, arc flash reduction, diagnostics, and system monitoring and communications are all features available by selecting the appropriate trip unit for the specific requirement. True RMS sensing offers increased accuracy and reliability.

Cutler-Hammer Breaker Trip Unit, Type LES Thermal Magnetic, Series: C, 3 Pole, 600 A, LE Breaker Frame Type, For Use With: Series C- LD, HLD, LDC, CLD, CHLD, CLDC Molded Case Circuit Breaker Frame, 7.28 in H x 1.5 in W x 3.44 in D

• IDW ITEM DOCUMENTS https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1511876430515.pdf
• IDW ITEM DOCUMENTS https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/http://www.ideadigitalcontent.com/files/10964/ID-SPE-v1-LES3600LS.pdf

• 40 deg C operating temperature
• 600 VAC voltage rating
• Bolt-on mounting
• Long-time and short-time (LS) function
• Adjustable IR switch allows for continuous current settings and eliminates the need for rating plug
• Long delay I2t setting with variable trip times
• Long, short, instantaneous, and ground fault protection
