Eaton's 10250T line of 30.5 mm pushbuttons features a heavy-duty zinc die cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions. In addition, drainage holes prevent the buildup of liquid inside the operator, which can prevent operation in freezing environments.

EATON Pushbutton/Indicating Light, Full Voltage Heavy Duty Oiltight/Watertight Standard Actuator, Series: 10250T, 120 VAC, 0.5 A, Fresnel Lens, Green Lens, Plastic Lens, LED Lamp, Bezel/Housing: Polished Chrome, 30.5 mm, Round, Bayonet Base, 60000 to 100000 hr Average Life, Pressure Plate Terminal, NEMA 3/3R/4/4X/12/13/IP65, Panel Mount, Environmental Conditions: 1 to 150 deg F Operating, 95% Relative Humidity at 60 deg C

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_10250T197LGP2A_Specification_Sheet.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_10250T197LGP2A_Specification_Sheet.pdf
• VIDEO LINK http://videos.eaton.com/detail/video/6243433319001/how-to-size-and-select-a-power-supply?autoStart=true&q=power%20supplies

• 2.4 in L x 2.1 in W x 3.2 in H
