EATON BAB3040HS1 Quicklag Type BAB Miniature Circuit Breaker, 240 VAC, 40 A, 10 kA, 3 Poles, Non-Interchangeable/Thermal Magnetic/Shunt Trip

  • MPN: BAB3040HS1

  • IESPN: 12267

  • UPC: 786679378106

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability

QUICKLAG is the largest and most complete family of industrial thermal magnetic miniature circuit breakers. They provide the exclusive features of steel frame calibration and arc chutes in every pole. QUICKLAG circuit breakers are provided in ranges from 5 to 125 A continuous in single, two and three pole configurations with interrupting capacities from 10 to 65 kA. QUICKLAG circuit breakers have been series rated up to 200 kA in conjunction with larger Westinghouse/Cutler-Hammer current limiting circuit breakers. Each QUICKLAG rating is available for plug-in (Type P), bolt-on (Type B) and cable to cable connections (Type C) for line/load feed applications. They are also available with one of the industries widest selection of accessories, including shunt trip and can be custom modified to meet special application requirements.

EATON Miniature Circuit Breaker, Type BAB, Series: Quicklag, 240 VAC, 40 A, 60 Hz, 10 kA Interrupt, Non-Interchangeable/Thermal Magnetic/Shunt Trip, 3 Poles, 3-Phase, Extended Tang Line Terminal, 14 to 4 AWG Wire, Bolt-On Mount, 40 deg C, 2.94 in H x 3 in W x 2.38 in D

Type      Type BAB
Series      Quicklag
Voltage Rating      240 VAC
Amperage Rating      40 A
Frequency Rating      60 Hz
Interrupt Rating      10 kA
Trip Type      Non-Interchangeable/Thermal Magnetic/Shunt
Number of Poles      3
Phase      3-Phase
Connection Type      Extended Tang Line Terminal
Wire Size      14 to 4 AWG
Mounting Type      Bolt-On
Temperature Rating      40 deg C
Dimensions      2.94 in H x 3 in W x 2.38 in D
  • pdfBrochure
  • pdfBrochure
  • pdfCatalog
  • pdfSpecification Sheet
  • pdfSpecification Sheet
  • pdfSpecification Sheet
  • Special Features: 24,48V shunt trip
  • Quantity: 8
  • Circuit Breaker Type: BAB
  • Notes: HACR rated
  • Warranty: 1 Year
