GE THQL1115AF Q-Line® Arc Fault Circuit Breaker, 120/240 VAC, 15 A, 10 kA, 1 Poles, Non-Interchangeable Trip

  • MPN: THQL1115AF

  • IESPN: 54120

  • UPC: 783164267457

  • Min Order Qty: 1

  • Quantity Interval: 1

    • Availability: loading

    • Branch Availability

This is an arc fault breaker. Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QL breakers are plug-in versions of the Q line used for connection to load centers and lighting panels. All Q line circuit breakers feature quick-make/quick-break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. Q line breakers are available in 1, 2 and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories and can be ordered for use in HID applications.

GE Arc Fault Circuit Breaker, Series: Q-Line®, 120/240 VAC, 15 A, 10 kA Interrupt, Non-Interchangeable Trip, 1 Pole, 1, 1 in Plug-In Connection, 14 to 10 AWG Cu/Al Wire, 3-9/32 in H x 1 in W x 2-3/8 in D

Series      Q-Line®
Voltage Rating      120/240 VAC
Amperage Rating      15 A
Interrupt Rating      10 kA
Trip Type      Non-Interchangeable
Number of Poles      1
Phase      1
Connection Type      1 in Plug-In
Wire Size      14 to 10 AWG Cu/Al
Dimensions      3-9/32 in H x 1 in W x 2-3/8 in D
  • pdfCatalog-1
  • pdfData/Spec Sheet-1
  • pdfSpecification Sheet
  • pdfSpecification Sheet
  • Fixed thermal magnetic trip unit
  • Fixed long time
  • Fixed instantaneous
  • Suitable for reverse feed
  • Continuous current rated: Standard
  • Trip function: LI
  • Special markings: HACR, SWD
  • Feeder plug-in circuit breakers
  • R9 GO schedule
