Optimum product quality, tested reliability and safety stand for best protection of personnel, installations and plant. EATON WMZS DIN rail mountable circuit breaker is designed for use in control panel applications. The WMZS is available with B, C and D characteristics in accordance with UL 1077, CSA C22.2 No.235 and IEC 60947-2.

Cutler-Hammer Supplementary Protector, Series: WMZS, 277/480 VAC, 63 A, 10 kA Interrupt, Curve C/Thermal Magnetic Trip, 3 Pole, 3 Phase, Standard Box Terminal, 18 to 4 AWG Wire, IP20, DIN Rail Mount, 23 to 104 deg F, 3.15 in H x 2.07 in W x 2.36 in D, Nylon

• Brochure https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Cutler_Hammer_WMZD1C05_Brochure.pdf
• Catalog https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Cutler_Hammer_WMZD1C05_Catalog.pdf
• Catalog-1 https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Cutler_Hammer_WMZD1C05_Catalog_1.pdf
• Specification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Cutler_Hammer_WMZS3C63_Datasheet.pdf
• Technical Bulletin https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Cutler_Hammer_WMZS1B07_Technical Bulletin.pdf

• Complete range of UL 1077 DIN rail mounted supplementary protectors from 0.5 to 63 A current rating
• Current limiting design provides fast short circuit interruption that reduces let through energy, which can damage the circuit
• Thermal magnetic overcurrent protection
• Trip free design breaker can not be defeated by holding the handle in the ON position
• Captive screws cannot be lost
• Dual rated for IEC 60947-2 standard
• Field installable shunt trip, auxiliary switch and undervoltage release
• Complete bus bar system available for quickly installing multiple breakers in panel assembly
• Module width of only 17.7 mm (per pole)
• Contact position indicator red - green
• Possibility for sealing the toggle in "ON or OFF" position
