Eaton’s fusible panelboard and switchboard switches are designed for commercial, industrial and service entrance applications to protect and switch feeder and branch circuits. Each panelboard unit includes a switching contact structure with an instantaneous trip element. Additionally, switches are available for both existing FDPW and distribution panelboards.

EATON Panelboard Switch, Type FDPW Fusible Branch Horizontal Twin, 600 V, 100 A, 30 hp, 60 hp, 75 hp, 3 ph, 3 Pole, 200 kA Short Circuit, Class J Insulation, Panel Mounting, 26-1/4 in L x 8 in W x 10 in H Dimensions

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/FDPWS363J_User_Manual.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/FDPWS363J_User_Manual.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_FDPWT3633J_Specification_Sheet.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_FDPWT3633J_Specification_Sheet.pdf

• Interlock mechanism prevents the switch cover from being opened with the switch mechanism in the on position for optimum security
• Ability to padlock in the On/Off position offers increased safety
• When used with current limiting fuses, they can be used as the upstream device in series-combination rated systems as well as in fully rated and selectively coordinated systems
• 14 to 1/0 AWG wire
• 30 hp at 240 VAC, 60 hp at 480 VAC, 75 hp at 600 vac horsepower rating
