The passive infrared (PIR) vacancy sensor detects motion from a heat-emitting source within its field-of-view to automatically switch lights Off, offering the same performance features as the ODS family of occupancy sensors. OSS10 has the ability to reduce (dim) and turn OFF the 'Guide Light' function with a simple dial setting. The LED nightlight consumes less than 1/2 W providing energy savings and guide lighting when room lights are off. OSS10 is perfect for use in hospitality and health care facilities with night light feature to guide to manual-on. The adjustable time delay settings of 30 sec to 30 min will automatically turn lights Off. The nightlight occupancy sensor wall switch can be used to provide automatic lighting control for energy savings and convenience in a variety of commercial applications.

Leviton® Decora® Vacancy Sensor, 1-Pole, Series: OSS10, 120/230/277 VAC, 190/350/410 mW Power, PIR Sensor, 1200 sq-ft Coverage, 180 deg Viewing, 30 s to 30 min Time Delay, Fluorescent/Incandescent Lamp, 60 Hz Response, 0 to 50 deg C, White, 1.75 in W x 1.83 in D x 46 in H Dimensions

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Decora_OSS10_INE_Catalog.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Decora_OSS10_INE_Catalog.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Decora_OSS10_INE_Manual.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Decora_OSS10_INE_Manual.pdf

• Fits in standard wallbox and replaces 1-pole wall switch, ground and neutral connection required, gangable with other units
• Low profile design eliminates obtrusive "scanning device" look
• Elegant Decora® wallplates compliment any interior for sleek aesthetics, uses Decora® wallplates and coordinates with Leviton® popular line of Decora® wiring devices
• 180 deg field of view provides approximately 2100 sq-ft of coverage
• Convenient pushbutton provides manual ON/OFF light switching at any time
• Two dual element PIR sensors used to widen detection range and double the detection points within the FOV
• Segmented fresnel lens provides optimum sensitivity and performance
• Designed with an extensive ''minor motion'' area where even slight body movements will be detected
