The complete family of transformers from GE provide quiet, reliable transformer operation. All of the dry type transformers through 1,000 kVA are UL listed under the requirements of Standard 506 and 1561. In addition, each transformer meets the requirements of NEMA ST-20, 1992. Type QB, QMS, and QMS 3 models are C-UL listed. general purpose transformers are rated 600 Volts and below for supplying appliance, lighting, and power loads from electrical distribution systems. Standard distribution voltages are 600, 480, and 240 Volts; standard load voltages are 480, 240, 208, and 120 Volts. The transformer is used to obtain the load voltage from the distribution voltage. Since no vaults are required for installation, these transformers can be located right at the load to provide the correct voltage for the application. This eliminates the need for long, costly, low voltage feeders.

GE Transformer, Type QB Dry Encapsulated General Purpose, 120/240 VAC Primary, 12/24 VDC Secondary, 0.25 kVA, 60 Hz, 1-Phase, Lug/Bolt Down Terminal, 8175 Frame, Wall Mount, IS-12, NEMA 3R, 40 deg C, Steel Housing, 7.4 in H x 6.1 in W x 4.2 in D

• Specification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1520590565186.pdf

• Core and coils are contained within a NEMA 3R nonventilated weatherproof enclosure
• Type QB and QMS units feature encapsulated core and coils
• No taps
• K1 K-factor
• For bucking and boosting voltage
• Knockouts provided on back and bottom
• High grade silicon steel core
• Mounting holes on side for easy access
• Wiring compartment includes ground stud
