Eaton's M22 selector switch line offers an almost endless variety of options in maintained/momentary, key removal and illuminated devices. The coding adapters used for maintained/momentary and key removal positions make the M22 stand out from competitive devices. By simply adding or removing a coding adapter from inside the operator, the end-user can change the function of the button. Operator options include standard knob, rotary head, illuminated and keyed versions. As with all operators, they can be ordered as a ready to install complete device or as modular components to meet application specific requirements.

Cutler-Hammer Non-Illuminated Selector Switch, Series: M22, 22.5 mm, 1NO-1NC, Maintained Contact Mode, Knob Operator, 2 Positions, NEMA 4X/13/IP67/IP69K, Black Bezel

• IDW ITEM DOCUMENTS https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1515127694199.pdf
• Catalog https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Cutler_Hammer_E30KA100_Catalog.pdf
• Specification Sheet https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/Cutler_Hammer_M22S_WKV_K11_Data_Sheet.pdf
• IDW ITEM DOCUMENTS https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1516382788713.pdf
• IDW ITEM DOCUMENTS http://www.eaton.com/ecm/idcplg?IdcService=GET_FILE&allowInterrupt=1&RevisionSelectionMethod=LatestReleased&noSaveAs=0&Rendition=Primary&dDocName=PA04704002E
• IDW ITEM DOCUMENTS http://www.eaton.mx/ecm/idcplg?IdcService=GET_FILE&allowInterrupt=1&RevisionSelectionMethod=LatestReleased&noSaveAs=0&Rendition=Primary&dDocName=PCT_1606430
• Video Link https://www.youtube.com/watch?v=_nJTR29VEFM

• Most pushbutton operators and contact blocks exceed 5 million mechanical operations
• This highly versatile line features field-convertible functions and customized laser engraving capabilities
• Adding or removing coding adapters allows for field convertibility of maintained/momentary and key removal positions
• LED offering only for improved brightness quality and up to 100000 hr of operation
• More than 100000 mechanical operations
• Coding adapter options make assembly fast and simplify stocking of different configurations of selector switches
• Capable of communicating via Asia protocol with Asia adapter modules
• 1.46 in L x 1.18 in W x 3.86 in H selector switch
