Eaton offers a complete line of Type AP, MTE and MTK Industrial Control Transformers, which provide stepped-down voltages to machine tool control devices. Each unit must pass rigid tests for turns ratio, insulation, continuity, and over potential. Performance meets or exceeds ANSI/NEMA ST-1 requirements. With a 50-60 Hz operation standard, transformers are designed for loads requiring extremely good regulation. Regulation also exceeds ANSI/NEMA requirements.

EATON Control Transformer, Type MTE, 240/416/480/600, 230/400/460/575, 220/380/440/550, 208/500 V Primary, 99/120/130, 95/115/125, 91/110/120, 85/100/110 V Secondary, 250 VA Power, 50/60 Hz Frequency, 1 ph, Molded-In Connection, 130 deg C Insulation, 55 deg C, 5.866 in L x 4.488 in W x 3.819 in H Dimensions

• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/C0250EBHFBFS_User_Manual_01.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/C0250EBHFBFS_User_Manual_01.pdf
• https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/C0250E6U_Specification_Sheet_02.pdf https://www.iesbuy.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/C0250E6U_Specification_Sheet_02.pdf

• Epoxy encapsulated coil design
• Laminations of high quality, silicon steel minimize core losses and optimize performance
• Copper magnet wire for high quality, efficient operation
• Secondary fuse clips where applicable
• Performance meets/exceeds requirements of ANSI/NEMA ST-1
• Regulation exceeds ANSI/NEMA requirements for all ratings
• Molded-in terminals for maximum durability
• No taps
